Martin Audio X8 8" Passive Two-way Portable Loudspeaker

Speakers was used just for demo in the showroom, never transported.



The Blackline X8 is an ultra-compact passive two-way system with an 8” (200mm)/2” (50mm) voice coil LF driver and a 1” (25mm) HF driver mounted on a 90° x 50° horn which can be easily rotated for horizontal or vertical orientation, depending on venue requirements. Its very small size gives no indication of its high output capability.

Ultra-Compact passive two-way system
Symmetrical multi-angle plywood enclosure
User-rotatable 90° x 50° horn
Vertical and horizontal orientation
Screw-free, cloth-backed perforated steel grille
Integral ergonomic handle
Pole-mount bung maintains clean lines
8Ω nominal impedance
Twin NL4 connectors
Flexible mounting options via M8 inserts
FREQUENCY RESPONSE (5)70Hz-20kHz ± 3dB, -10dB @ 60Hz

DRIVER LF: 8” (200mm)/2” (50mm) voice coil, ferrite motor system
HF: 1” (25mm) exit/1” (25mm) voice coil, polyimide dome compression driver

RATED POWER (2)200W AES, 800W peak

SENSITIVITY (8)92dB

MAXIMUM SPL (9)115dB continuous, 121dB peak

NOMINAL IMPEDANCE 8Ω
