Void Acoustics Arcline X (PU coating white)

Verkaufe Void Acoustics Arcline X subs.
Zustand 1A
fresh repainted and refurbished all HTT grills and skrews.
Subs coming with grills.
shipping world wide (prefer EU).
Also in WIne red available.

Make special deal for the lot.




Frequency Response: 38 Hz - 250Hz -3dB

Efficiency: 105 dB 1w/1m
Crossover Point: 38Hz Hi Pass - up to 250Hz Lo Pass
Impedance: 4 ohm
Power Handling: 1500 watts
Maximum Output: 136 dB cont, 140 dB peak
Driver Configuration: 2 x 15" neo
Dispersion: Array Dependent
Connector: 2 x 4 pole speakon
Height (mm): 446
Width (mm): 860
Depth (mm): 800
Weight (kg): 64.8
Enclosure: 18mm birch plywood - Carbon Fibre - Magnesium
Rigging: 3.2 m tower winch system
Finish: Textured Polyurethane white
Grille: Perforated steel - foam filter

Applications: Live sound in medium sized venues. Small to medium scale touring. Theatre, AV presentations, music clubs

Expanding on the multiple resonant chamber concept as found in the Stasys X, the Arcline X takes an even bigger break from tradition by distilling the technology one step further. Each enclosure offers 140dB peak SPL, whilst an array capable of 150dB peaks occupies a frontal area of only 3 sq meters and can be setup in less than 2 minutes by two people.

The radical advance of the multiple resonant chamber technology employed by Arcline X additionally allows a sub 40Hz f3 point, which is unprecedented for an enclosure with a volume of just 300 litres.

Careful design consideration of the internal horn paths have resulted in an extended upper response that will accurately reproduce up to 250Hz, permitting a higher crossover frequency than is possible with many other subwoofers. When used with the Arcline 6 or Arcline 12, this higher crossover raises their maximum output level capability and allows far greater projection of the important upper bass frequencies that many small line source's fail to reproduce convincingly.

Arcline X additionally features HTT (Heat Transference Technology). A side located heatsink is used to transfer heat from both woofer's voice coils and magnet assemblies, significantly decreasing power compression and improving long term reliability.
