LG LAPA 163 - 163'' All-in-One SMD LED

LG LED All-in-One LAPA163
Brand New

Key Feature

Screen Size : 163"
Pixel Pitch : 1.88 mm
Brightness : 500 nit (Max., after calibration)
Screen Resolution : 1,920 × 1,080

Tech Spec
Physical Parameter
Pixel Pitch (mm) 1.88
Module Resolution (W x H) 160 × 90
Module Dimensions (W x H, mm) 300 × 168.75
Screen Resolution (WxH) 1,920 × 1,080
Screen Dimension (W x H x D,mm) 3,605 × 2,030 × 29.95 (Thickest 59.5)
Screen Weight (kg) 155
No. of Modules per Screen (W x H) 12 × 12 (Total 144)
Screen Surface Area (㎡) 7.29
Physical Pixel Density (pixels/m²) 284,444
Flatness of Cabinet ±0.15 (TBD)
Cabinet Material Aluminum
Service Access Front
Optical Specifications
Brightness (After Calibration) 500 (Typ.)
Color Temperature (K) 3,200-9,300
Visual Viewing Angle (Horizontal/Vertical) 150 / 150
Brightness Uniformity 98%
Color Uniformity ±0.015 Cx, Cy
Contrast Ratio 3,000 : 1
Processing Depth (bit) 16
Electrical Specifications
Power Consumption (W/Screen, Max.) 2,000
Power Consumption (W/Screen, Avg.) 750
Power Consumption (W/m², Max.) 275
Heat Dissipation (BTU/h/Screen, Max.) 6,825
Heat Dissipation (BTU/h/Screen, Avg.) 2,560
Heat Dissipation (BTU/h/㎡, Max.) 939
Power Supply (V) 100 to 240
Frame Rate (Hz) 50 / 60
Refresh Rate (Hz) 3,840
Operation Conditions
Lifetime (Hours to Half Brightness) 100,000
Operating Temperature (°C) 0 to +40
Operating Humidity 10-90% RH
IP rating Front / Rear IP30 / IP30
Sound
Speaker Built-in (9 W + 9 W)
Certification
Certification CE, FCC, ETL, CB, CE-RED EMC Class A
Fire Protection BS476: Part7 Class 1 EN13501-1 (Class B-s1,d0)
Environment
Environment RoHS, REACH
Controller
Controller Embedded (webOS)
I/O port
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Digital Audio Out (1, SPDIF Optical)
Wi-Fi / BT
Yes / No
ETC
IR Remote(In-box), Magic Remote : Not Supported
Side by Side : Yes (1xN)
HDCP 2.2
Crestron Connected
