Icon Edge Compact Hybrid Luminaire

Icon Edge Compact Hybrid Luminaire
Order now: https://cuesale.com/product/prg-icon-edge-compact-hybrid-luminaire/


The Icon EDGE is a very compact, feature rich, lightweight, fast beam/spot/wash luminaire. It combines an ultra-bright beam, with sharp gobo projection, a CMY-color mixing system and variable CTO. Fitted with the new Philips Platinum 21R lamp (470W), Icon EDGE outputs an amazing 20,000 Lumens.
Featuring 2-24 degree zoom in beam mode, and 2.5-32 degree zoom in spot mode, eight rotating gobos and 14 fixed, a continuous animation wheel and two prisms the Icon EDGE has a huge amount of creative options. A newly designed system provides extremely smooth, full field dimming. The fixture can take direct Art-Net input, as well as DMX512. Icon EDGE is a multi-use luminaire, with full animation wheel, beam, spot and wash function in one fixture.

Features :

20,000 Lumen output
Extremely narrow ACL beam with zoom
Even spot function
Large Zoom range
Full 16bit CMY + incl CTO
14 + Open fixed colour wheel
8 + Open interchangable rotating gobos
Custom glass gobo mode available
14 + Open fixed Gobo
Continuous animation wheel
2 Prisms (8 facet, linear 4 facet)
Split colours
Drop In frost
Ultra-fast Pan/Tilt movement
Can be mounted in any orientation
Specifications :

Lamp : Philips Platinum 21R
Colour Temperature : 7800K
Beam Angle (beam) : 2-24º
Beam Angle (Spot) : 2.5-32º
Beam Angle (Wash) : 3.5-39º
Lumens Output : 20.000
Nominal Lifetime : 750 hrs
Focus : adjustable focus
Frost : drop-in
Colour wheel : 14 + open
CMY : 0-100%/ 16bit
CTO : 0-100%/ 16bit
Rotating Gobo : 8+ open
Indexing Gobo : yes
Fixed Gobo : 14+ open
Prism : 8 facet + lin 4 facet
Indexing Prism : yes
Animation Wheel : continuous
Indexing Animation Wheel : yes
Shutter/Strobe : variable, 13 flash/sec
Dimmer : 0-100%/ 16 bit
Pan/Tilt : 540/270º
DMX Control Mode : 2 (25, 36 CH)
RDM : yes
Art-Net : yes
Self Charging Battery : yes
Cooling System Monitoring : yes
Wattage : 650W
Power : AC100-240V, 50/60hz
Operating Temperature : -10º to +45ºc
Certification : CE & cETL
Weight : 31kg
Dimensions LxWxH (mm) : 453x319x709


€695,00 Ex V.A.T. (MwST) per piece.

Prices are Excluding 21% VAT / MwSt.

Products are located in The Netherlands, customers with a V.A.T. ID number pay 0% V.A.T. / MwSt
Please send us your full address for a shipment quote / price.

For more used equipment check our other advertisements on this site or have a look at our website www.cuesale.com
